LMA conductivity meters: analogue, Modbus and high pressure

LMA3

The LMA series combines a conductivity transmitter and measuring cell in a compact unit for measurements in liquids. Select the version that suits your application and the interface of your control system.

Select the right LMA version

The measuring range, cell constant and measuring cell material depend on the selected version. Technical specifications and available options are listed on each product page.

Configuration and downloads

LMA devices with analogue or switching outputs and MW22

The existing configuration software and related documents are available for these devices:

LMA-MODBUS with RS-485

For the Modbus device, use the PC monitor and Modbus manual (ZIP, English/German). The current data sheet with the 4-pin connector assignment is available on the LMA-MODBUS product page.

Current Modbus software versions

LF-TR-MOD firmware 1.12 and Windows Monitor 1.16. Current data sheets and Modbus manuals are available on the product pages. For IO-Link via the Banner S15C-MGN-KQ, the product pages also provide the customer package with the original IODD and register mapping.

HP LMA high-pressure conductivity meter, 200 bar at 100 °C
NEW

HP LMA: 200 bar at 100 °C. Conductivity 0.001–2000 µS/cm, cell constant 0.01 cm-1, Pt1000. Cell materials: 316L, PEEK and EPDM; G 3/4″. RS-485 / Modbus RTU; optional IO-Link via the preconfigured external Banner S15C-MGN-KQ. PC monitor 1.16. Converter surcharge: EUR 194; please request a quote.

1.792,00 EUR
plus 19% tax
LMA-MODBUS conductivity meter with RS-485 and PP measuring cell
TOP

LMA-MODBUS with RS-485 and Modbus RTU. Standard: cell constant 0.1 cm-1, PP measuring cell. Cell constants 0.01 and 1 and PVDF on request. LF-TR-MOD firmware 1.12, PC monitor 1.16. Current data sheets and software in the downloads section.

286,00 EUR
plus 19% tax
LMA-LED CC01 PP
LMA-LED CC01
Programmable, with:
LED indicator green / green-red / red
Piezo beeper
Opto-relay output
Current output: 0(4)...20mA
Cell constant: 0.1
Measuring cell material: PP
Please inquire about measuring cells made of PVDF.
286,00 EUR
plus 19% tax
LMA-LED CC001 PP
LMA-LED CC001 PP
Programmable, with:
LED indicator green / green-red / red
Piezo beeper
Opto-relay output
Current output: 0(4)...20mA
Cell constant: 0,01
Material of measuring cell: PP
Please inquire about PVDF as a material for the measuring cell.
306,00 EUR
plus 19% tax
LMA-LED CC01 PVDF
LMA-LED CC01 PVDF
Programmable, with:
LED indicator green / green-red / red
Piezo beeper
Opto-relay output
Current output: 0(4)...20mA
Cell constant: 0,1
Material of measuring cell: PVDF
326,00 EUR
plus 19% tax
LMA-I CC1 PP
LMA-I CC1 PP
Programmable, with:
Current output: 2 x 0(4)...20mA
Cell constant: 1
Material of measuring cell: PP
Please inquire about PVDF as a material for the measuring cell.
306,00 EUR
plus 19% tax
LMA-I CC01 PP
TOP
LMA-I CC01
Programmable, with:
Current output: 2 x 0(4)...20mA
Cell constant: 0.1
Please inquire about cell constants of 1.0 and 0.01.
Measuring cell material: PP
Please inquire about measuring cells made of PVDF.
286,00 EUR
plus 19% tax
LMA-I CC001 PP
LMA-I CC001 PP
Programmable, with:
Current output: 2 x 0(4)...20mA
Cell constant: 0,01
Material of measuring cell: PP
Please inquire about PVDF as a material for the measuring cell.
306,00 EUR
plus 19% tax
LMA-I CC01 PVDF
LMA-I CC01 PVDF
Programmable, with:
Current output: 2 x 0(4)...20mA
Cell constant: 0,1
Material of measuring cell: PVDF
326,00 EUR
plus 19% tax
LMA-I 1000 PP
LMA-I 1000 PP
Measuring range up to 1000 mS/cm
Programmable, with:
Current output: 2 x 0(4)...20mA
Cell constant: 0.1
Please inquire about cell constants of 1.0 and 0.01.
Measuring cell material: PP
Please inquire about measuring cells made of PVDF.
286,00 EUR
plus 19% tax
LMA-F CC01 PP
LMA-S ZK01
Programmable, with:
2 x switching output or frequency output
Cell constant: 0.1
Please inquire about cell constants of 1.0 and 0.01.
Measuring cell material: PP
Please inquire about measuring cells made of PVDF.
256,00 EUR
plus 19% tax
Configuration cable for LMA

0022.8098 Configuration
You do not want to configure yourself?
No problem. We will gladly do the configuration for you.
Just install the LMA and connect it, done.


10,00 EUR
Connection cable M12 5pol.
M12-GX12 connection cable for LMA,
3m, 5 pin x 0,25 qmm, PVC cable shielded,
protection class IP 67
28,00 EUR
plus 19% tax
Connection cable M12 5pol.
M12-GX12 connection cable for LMA,
6m, 5 pin x 0,25 qmm, PVC cable shielded,
protection class IP 67
37,00 EUR
plus 19% tax
pH-/Redox cable
Cable LIYCY 5x 0,25 shielded, 1m,
For a connection cable with 50m length please order:
1 x M12-GX12 connection cable for LMA, 3m, 0022.8083 +
47 x this article.
3,00 EUR
plus 19% tax
